RUGGED ENCLOSURES & 19 INCH AMAZON RACKS

Amazon Racks combine the tough resilience of a rotomoulded double lid rack case with a lightweight 19” chassis and a unique elastomeric suspension system. They are designed to protect more fragile equipment, including electronics, IT and telecommunications, from challenging physical and climatic environments though the 5 x Climate Zones from the Tropics to the Polar caps. Sway space between the rack frame and the rotomoulded rack case outer body allows for maximum chassis excursion, thereby minimising shock, vibration and impact damage during rough handling and demanding applications. CP Cases Amazon Racks feature all of the benefits of our range of Amazon Cases, including the patented male-female lid groove to prevent lid displacement due to sideways forces.

KEY FEATURES

Enhanced ‘sway space’ between inner frame and outer case to prevent contact with outer container
All of our 19 inch Amazon Racks have a ‘user adjustable’ inner frame allowing back to front movement of 50mm within the outer container to accommodate front panel and rear wiring / connector needs
Optional ‘EasyGlide’ removable, self anchoring, internal frame system
Standard, stainless steel M6 threaded fasteners secure electronic equipment into floating stainless steel cage nuts at both front and rear of frame
Positive stacking, aligning at the front face regardless of rack depth
Eight elastomeric anti-vibration mounts (AVMs) set at a 45° angle towards centre of the rack frame

DIMENSIONS

rack size (u):4U - 14U

internal rack depth (mm):480mm - 870mm

external width (mm):583mm

external height (mm):328mm - 773mm

external depth (mm):740mm - 1185mm

weight (kg):15.4kg - 26.2kg
